SH Series 2-16 Pins Vertical Crimp Bar Connectors

The SH Series 1.0mm Pitch Vertical Crimp Bar Connectors are designed to meet the demands of high-density interconnect applications, offering a compact and reliable solution for modern electronic devices. Available in 2 to 16 pin configurations, these connectors are ideal for environments where space is limited and performance is critical.

With a 1.0mm pitch, the SH Series provides a small footprint while maintaining strong electrical performance. This makes it particularly suitable for use in consumer electronics, industrial control systems, communication equipment, and compact medical devices, where internal space optimization is essential.

The vertical orientation of these connectors allows for efficient vertical mating to PCBs, enabling clean and organized wiring layouts. The crimp bar design supports stable wire attachment, ensuring secure and vibration-resistant connections even in demanding environments. The connectors feature a reliable locking structure and polarized housing, which help prevent misconnection and ensure accurate alignment during assembly.

Constructed from high-quality insulating materials and plated contacts, the SH Series connectors offer good durability and conductivity, ensuring consistent performance over extended periods. The connectors are also compatible with automated crimping and insertion processes, supporting efficient large-scale production.

The SH Series 1.0mm Pitch Vertical Crimp Bar Connectors (2-16 pins) offer a space-saving, high-reliability solution for applications requiring high-density wire-to-board connections. Their vertical design, secure crimp technology, and wide pin range provide designers with flexibility and performance in compact electronic assemblies.
