The PA-H-NAD 2.0mm Polarized SMT Header TE/JST-Style Latch-Type Board Connector is a cutting-edge, reliable solution designed to enhance the performance and safety of electronic connections. Featuring a 2.0mm pitch, this connector is optimized for applications where space is limited but secure and efficient connections are still required. With its SMT (Surface-Mount Technology) design, it can be easily integrated into compact circuit boards, making it ideal for modern electronics, including consumer devices, industrial automation, and telecommunications equipment.

One of the standout features of the PA-H-NAD connector is its patented fool-proof design, which ensures correct orientation and prevents incorrect connections during installation. This polarized design smalls the risk of damage due to improper mating, making it an essential component for high-reliability applications where precision is critical. The latch-type mechanism further secures the connection, providing additional stability and preventing accidental disconnections even in high-vibration environments.

This connector is built to meet the rigorous demands of modern electronics, offering good durability and performance under various operating conditions. The TE/JST-style ensures compatibility with a wide range of crimp terminals, making it versatile and adaptable to different wire sizes. It is especially beneficial in environments where space is at a premium but robust performance and ease of assembly are paramount.

Ideal for use in compact and mission-critical systems, the PA-H-NAD 2.0mm Polarized SMT Header TE/JST-Style Latch-Type Board Connector provides a secure, fool-proof solution for creating reliable, high-quality electrical connections. Its space-saving design, ease of use, and patented safety features make it an invaluable component in today’s demanding electronics landscape.

Specifications:



Product Category

PCB

Pitch (mm)

2.0

Pin

2-16P

Current Rating

3A

Voltage Rating

250V AC,DC

Withstanding Voltage

800V AC  1 Min

Contact Resistance

20mΩ Max

Operating Temperature

- 25°C  ~  85 °C

Pin Material

Brass (Tin Plating)

Housing Material

PA or PBT UL94V-0



Basic Info.



Model NO.

PA-H-NAD

Application

PCB

Certification

CE,ISO9001 ,ROHS Reach,CQC, PAHS,TSCA,PAES

Terminal Material

Phosphor Bronze with Tin or Gold Plating

Services

ODM/OEM

Color

Black/Beige

Market

Asia, America, Europe, Mid-East, Africa

Main Products

Connector, Terminal, PCB Connector

Package

Tape Reel

Sample

Free

Delivery Time

Stock goods within 1 day, Customized 7 days

Terms of Trade

EXW, FOB, CIF, CPT

Specification

Electrical terminal Connector

Trademark

KUAILI

Origin

Zhejiang, China (Mainland)

HS Code

8736909000



Production Equipment



Equipment Name

QTY

Origin

Injection Molding Machine

64

China

High-speed Stamping Press Machine

37

Taiwan &Japan

Automated Press-Fit Production Line

103

China

SMT Patch Packing Inspection Machine

128

China

Automated Tape-and-Reel Packaging

20

China

Fully Automatic Optical Counting Packing machine

1

China

Y-axis Inspection Machine

8

Germany

Sodick EDM Machine

3

China

Sodick Wire EDM Machine

3

China

Specification:
